EL10B TUTORIAL #1   Friday, 8 September 2000

1. Draw gate diagrams to implement the Exclusive-OR and Exclusive-NOR functions using only AND, OR, NOT gates.

2. Simplify the following Boolean expressions using the rules given you in class:

3. Write the Truth Table for a 3-input AND gate.
